19 21.5 28 38 49 65 75 80 inch hd ultra-wide stretched advertising lcd bar display monitor lcd digital signage stretch bar screen shelves advertsing display with andriod OS or Windows OS
These products have in tock.
1—we can cstomize it as display monitor(for monitor,for advertising display….)
2—we can customize it as all in one PC buit in android OS system or Windows system.
Please specify your preference and expectation for your applications so as we can quote accurate cost.
| Bar screen android tablet for business | ||
| System | CPU | Quad core cortex A9,1.6G,RK3188 (We can choose to use A64/RK3128/RK3288/RK3399 chip to design) |
| RAM | 1GB | |
| Internal memory | 8GB | |
| Operation system | Android 4.4 Default (If any Android 5.1/6.0/7.1,we need to change CPU) |
|
| Display | Panel | 19″bar screen (3.”9 ~59″ Design Option We can design the screen size according to customer requiement) We have done 21″/23.1/28.8/37/38/43.8(4K)/44.8/48.5/57.5/86/88″ before |
| Resolution | 1920*360 | |
| Active area | 476.64(H)x 89.37 mm(V) | |
| Viewing angle | 89/89/89/89(L/R/U/D) | |
| Display mode | Nomally black ,IPS | |
| Contrast ratio | 1200 | |
| Luminance | 300cd/m2 | |
| Aspect Ratio | Bar screen | |
| Network | WiFi | 802.11b/g/n |
| Ethernet | 10M/100M ethernet | |
| Buletooth | BT 4.0 | |
| Interface | USB Host x 3 | USB 2.0 |
| USB OTG | USB OTG | |
| SD card slot | SD/MMC card slot | |
| Earphone | 3.5mm earphone | |
| Power Jack | DC input | |
| RJ45 | Ethernet | |
| Media plays | Video format | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC1,RV etc. |
| Photo | jpeg | |
| Other | VESA | Wall mounting |
| Language | Multi-language | |
| Working temp | 0–40degree | |
| Power consumption | 30W | |
| Accessories | Adapter | Adapter,12V,3A |
| User manual | yes | |
What is the Specification of our kiosk?
|
Index |
Model |
GT43B |
|
|
Outside area (mm) |
720.5(W)*162(H)*56.4(D) |
|
|
Display area (mm) |
698.5(W)*140(H) |
|
|
Size |
28 inch |
|
Display |
LCD |
|
|
Dot pitch |
0.1845(H) *0.1845(V) |
|
|
Resolution |
1920×758 |
|
|
Brightness |
500-700cd (optional) |
|
|
Contrast |
3000:1 |
|
|
Viewing angle |
89/89 |
|
|
Response time |
8ms |
|
|
Color |
1677 million color |
|
|
Color Gamut |
92% |
|
|
Connection method |
Input method |
HDMI/VGA/DVI/BNC,Network board/(optional) |
|
Video input |
CVBS |
|
|
Control method |
RS-232 485 |
|
|
Network function |
optional |
|
|
Power |
Power consumption |
26W |
|
Standby power consumption |
5W |
|
|
Power management |
DC 24V |
|
|
Mechanical indicators |
Stand installation |
Need to be customized |
|
Weight |
5.18Kg |
|
|
Operating environment |
Operating temperature |
0℃~ 50℃ |
|
Humidity |
10~80% |
|
|
Altitude |
3000m |
|
|
Mean Time Between Failures |
50000 hours |
|
|
Auxiliary material |
System equipment connection wire |
customized |
|
Display unit bracket |
optional |
|
|
Connection wires |
, Power line, serial control line |
Product Pictures
23 inch ultra Wide stretched Bar digital media LCD Display for shelf edge
This is our Unique Design,hot used for coffee shops, hotels ,restaurant,shopping mall etc public places now.
It’s HOT selling because of tilt design, and portable friendly application.
For the functions, there are TWO Solutions for option:
One is Media Player USB solution, another is Android os WIFI network solution
Media Player USB solution main features are:
1. Auto loop play video and image when power on
2. Auto copy content from USB to SD card
3. Timer on and off
4.Support format:
Video: AVI,MKV,FLV,TS,VOB,TS,MKV, MPG, MP4,RM, RMVB etc
Audio: MP3,WMV
Photo: JPEG,BMP,GIF
5.Slide show, loop, repeat playing playing type
The second solution are Android OS network
With Content Management System (CMS ), the user may manage hundreds of displays from different location. It saves time, cost and management easily operate.
What’s more, the user may output the program to USB, and copy content to display by hand.
Most of all, the data analyze in the platform are helpful for advertising effect review.
